ESD Magazine Rack SMT PCB Turnover Racks

  • 1
  • 2
  • 3

Brand Name : Herzesd

Model Number : HZ-2608

Place of Origin : CN

MOQ : 5

Price : USD 35-50/ set

Delivery Time : 5-7 days

Adjust Type : Screw/ Gear Track

High Temperature Resistance : 80℃,120℃ And 200℃ Above Are Available

Usage : PCB Tunrover

Material : Plastic+Metal

Size : 535*460*570mm

Slot : 50

Contact Now

Anti-Static PCB Magazine for Automated Assembly

The anti-static magazine rack is made from high-quality ESD engineering plastics and metal components coated with ESD-safe materials. Its surface resistance is precisely controlled between 10⁶–10¹¹ Ω, allowing static electricity to be discharged instantly and safely. Even in complex environments, it provides stable, long-lasting protection for electronic components, precision instruments, and other static-sensitive products, preventing damage or performance degradation.
ESD Magazine Rack SMT PCB Turnover Racks

Size Chart:

Model Outer size(mm) PCB plate size(mm) Base material Adjust type Temp. Slots Weight
(KG)
HZ-2601 355*315*580 355*(80-250) Plastic Screw adjust. 80℃ 50 5
HZ-2602 355*315*305 355*(80-250) Plastic Screw adjust. 80℃ 25 3.4
HZ-2603 355*320*563 355* (50-250) Metal Screw / gear track 80℃/120℃/200℃ 50 5
HZ-2604 355*320*563 355* (50-250) Plastic Gear track 80℃/120℃ 50 4.5
HZ-2605 355*320*563 355* (50-250) Metal Screw / gear track 80℃/120℃ 50 6.5
HZ-2606 355*320*563 355* (50-250) Metal Gear track 80℃/120℃ 50 6
HZ-2607 460*400*563 460*(50-330) Metal Screw / gear track 80℃/120℃/200℃ 50 8
HZ-2608 535*460*570 535*(50-390) Metal Screw / gear track 80℃/120℃ 50 10.5
HZ-2609 535*530*570 535*(120-460) Metal Screw / gear track 80℃/120℃ 50 12
HZ-2610 630*530*570 630*(50-460) Metal Screw adjust. 80℃ 50 13
HZ-2611 355*320*560 355* (50-250) Plastic Chain adjust. 80℃ 50 6
HZ-2612 355*320*560 355*(80-250) Metal Screw / gear track 550℃ 50 6.8
HZ-2613 400*320*563 400*(50-250) Metal Screw / gear track 80℃ 50 6

Product Description: SMT ESD PCB Magazine Rack
EQUIPMENT AND PRODUCTS FOR THE ESD PRODUCTION LINE
PCB Magazine
ESD PCB Magazine Rack
SMT PCB Magazine Rack
SMT ESD PCB Magazine

ESD Magazine Rack SMT PCB Turnover Racks

ESD SMT PCB Magazine Racks:


A PCB Magazine or PCB Rack is made of volume conductive polypropyleneand metalwhich is used to transport the PCB boards for automated assembly lines
1.The SMT magazine rack is designed for PCBs manufacture, assembly, storage and transfer.
2.Adjustable through screws,gear adjustment.
3.Common type (60°C) and heat-resistance type(120°C ,160~200°C) are available.
4.Surface resistance: 104~106 ohm.
5.Base: P-Conductive PS, M-Zincification Iron
6.Adjustment: G-Gear track adjustment, S-Screw adjustment
7.Max tolerant temperature: 60°C,120°C,160~200°C different material 8.PCB slots:The number of the SMT magazine rack Can accommodate PCBs
